D-tect 150 SV wallscanner Professional

Ask For Price

D-tect 150 SV wallscanner Professional


The specialist for finding objects in difficult conditions

Technical data
Additional data
Detection depth, steel, max.* 150 mm
Detection depth, copper, max.* 150 mm
Max. detection depth* 150 mm
Detectable materials Plastic pipes, ferrous metals, non-ferrous metals, wooden studs, live cables
Detection depth of live cables, max. 60 mm
Detection depth of wooden substructures, max. 40 mm
Accuracy ± 5 مم mm
Automatic deactivation, approx. 5 minutes
Power supply 4 x 1.5 V LR6 (AA)
Weight, approx. 0.65 kg
Detection depths, max. (material) Ferrous metals, 150, Non-ferrous metals (copper), Plastic pipes (empty, diameter > 2 cm), 80, Plastic pipes (water-filled), Wooden substructures, 40, Live cables, 60
Detection depths, max. (mode) Concrete damp, 60, Concrete special, 150, Metal, Drywall construction, 80, Signal view, Universal mode, Floor heating
Display of max. drilling depth
Dust and splash protection IP 54
Additional function Signal view, reliable measurements in damp concrete



* Highlighted Data


The specialist for finding objects in difficult conditions

  • Unique: More reliable detection of objects in damp concrete
  • Millimeter-accurate detection of ferrous/non-ferrous metals, live cables, wooden studs, and plastic pipes
  • Digital display of material properties

Functions : Detection of metal neutral Millimetre-accurate detection of ferrous/non-ferrous metalsDetection of wires neutral Millimetre-accurate detection of live cablesDetection of wood neutral Millimetre-accurate detection of wooden studsDetection of plastic neutral Millimetre-accurate detection of water-filled plastic pipesDetection of plastic neutral Millimetre-accurate detection of plastic pipesDetection Humid Concrete Objects can be detected in humid concrete.Floor heating Precise detection of floor and wall heating systemsDepth specification The actual object depth is displayed, making it easier to determine the actual level of concrete cover.Raw signal Rather than indicating a single point on the display, the tool outputs the “raw signal”.Depth Indication Display of object’s depthDetection depth of metal Maximum detection depth 150 mmObject Tracking Displays the exact location of the detected objectSteel Millimetre-accurate detection of steelTolerance 5 mm Measuring accuracy of ± 5 mmIP protection 54 Dust and splash protection IP54


Bosch – Germany

SKU: D-tect 150 SV Category: Tags: ,
